Stainless Steel Telescopic Channel Drawer Slide Roll Forming Machine Telescopic Drawer Punch Machine With Factory Price
Boasts precision engineering that ensures intricate profile accuracy. Its notable features include versatility in material handling, high production efficiency, and the ability to create durable, high-quality drawer slide components, enhancing overall functionality and user satisfaction.
- SCN CNC
- Guangdong,China
- 45days
- 4sets/month
- Information
Introducing a range of innovative machines tailored to meet a variety of manufacturing needs: Drawer Slide Roll Forming Machines, Telescopic Drawer Punching Machines, Architectural Stud Forming Machines, Fire Rated Door Box Forming Machines and File Cabinet Forming Machines. Each machine is designed to provide superior performance, precision and reliability to meet a wide range of industrial applications.
Roll Forming Machines are engineered to form sheet metal into a variety of profiles with unmatched precision, ensuring consistent quality and reducing material waste. Their rugged construction guarantees long-term durability and minimal maintenance requirements.
Drawer Slide Roll Forming Machines are specifically designed to manufacture precise and durable drawer slide components for seamless operation and extended product life. Their advanced technology ensures high production efficiency and versatility to accommodate different materials and designs.
Telescopic Drawer Punching Machines are designed to produce telescopic drawer slides with superior strength and smooth function. Their precision punching capabilities guarantee accurate dimensions and enhanced performance, meeting the highest industry standards.
Architectural Stud Forming Machines are ideal for manufacturing high-quality architectural studs used in building and construction projects. Its efficient design ensures fast production speeds and consistent quality, helping to complete projects on time and in a cost-effective manner.
The Fire Rated Door Box Forming Machine is specifically designed to produce fire rated door boxes that meet strict safety and regulatory requirements. Its precision engineering ensures durability and reliability, providing the necessary protection in emergency situations.
Finally, the File Cabinet Forming Machine is designed to easily manufacture strong and functional file cabinet components. Its versatility allows for the production of a wide range of sizes and styles, meeting different storage needs and enhancing office organization.
Each machine in the series is carefully designed to provide excellent performance, precision and durability, ensuring the best results for your manufacturing needs.
No. | Device Name | Specification | Note | |
1 | Main Under Frame | Whole 450*200 H-beam | Flatness:±0.2mm | |
2 | Sidewall Driving Motor | 0.75KW/Set | 3 Sets Meiling RV Reducer | |
3 |
Forming Rollers |
Cr12 φ270 | vacuum heat treatmentafter CNC lathe upto HRC58~60℃,tolerance +0.05 mm 0.08mm | |
4 |
Shaft | 40Cr
One side: 70mm One side: 88mm | Forging treatmentafter CNC lathe uptoHRC28~32℃,then chromed plated after polishing,tolerance -0.02~0.05mm | |
5 |
Sidewall |
A sidewall 38mm | A3 Steel,CZ exchangeable position add safety pin components | |
6 | Feeding Unit | Guide Shaft & Guide Roller | ||
7 | Flatting Unit | 5 rolls (up 2 down 3) with 1 step lead | ||
8 | Straighting Unit | 2 rolls for 4 side |
| |
9 |
Punching after forming | Single Hole φ14 | Articulated, Punching die: Cr12 | |
DoubleHole14*25mm | ||||
H hole φ16mm | ||||
10 |
Cutting after forming | Stop to post and post to cut,raw material is Cr12Mov | Spare 150-300mm cutting blade |
